STAINLESS STEEL TANKS
Stainless steel tanks are the premium grade water storage solution with superior corrosion resistance. All components of the tank are made of austenitic grade stainless steel (grade 304 or 316). Being one of the most hygienic water storage solution, stainless steel tank is highly suitable for hospital, healthcare, restaurants and even food manufacturing sector.
Product comes with a set of standard items include 600mm x 600mm manhole, water level indicator and a standard design ladder (subject to project requirement and refer below for detail specification)
| STANDARD | Binasteel pressed steel sectional water tanks are hydraulically pressed to BS 1564:1975 Type 1 (combined double flange at an angle of 45° and 90° to the face of the plate on all four sides). |
| MATERIAL | Grade 304 stainless steel or 316 stainless steel. |
| THICKNESS OF PANEL | Depending on height of tank, conforms to BS 1564:1975. 4ft (1.22m) tanks: Bottom and sides – 5mm. 8ft (2.44m) tanks: Bottom and sides – 5mm. 12ft (3.66m) tanks: Bottom and sides – 5mm. 16ft (4.88m) tanks: Bottom and 1st tier of sides – 6mm, 2nd, 3rd and top tiers of sides – 5mm. 1m tanks: Bottom and side – 5mm. 2m tanks: Bottom and sides – 5mm. 3m tanks: Bottom and sides – 5mm. 4m tanks: Bottom and sides – 5mm. 5m tanks: Bottom and 1st tier of sides – 6mm, 2nd, 3rd, 4th and top tiers of sides – 5mm. |
| BRACING SYSTEM | Standard: Internal bracing system with stays and cleats. Made of grade 304/316 stainless steel. Optional: External reinforcement system with I-beams and tie rods. Made of hot dip galvanized steel. |
| BOLTS, NUTS AND WASHERS | Grade 304 stainless steel or 316 stainless steel. |
| JOINTING MATERIAL | Non-toxic PVC foam sealant. |
| TANK COVER | Supported by trusses and designed to support the weight of maintenance personnel. Manhole and air-vent(s) with insect-proof screen are included as standard. |
| LADDERS | Stainless steel internal ladder and external ladder. |
| LEVEL INDICATOR | Aluminium level indicator with reverse reading system. |
